QSFP-40G-SWDM4 40Gbps QSFP+ SWDM4 Transceiver, 350m Reach

QSFP-40G-SWDM4 40Gbps QSFP+ SWDM4 Transceiver, 350m Reach

Regular price $34.29 USD
Regular price Sale price $34.29 USD
Sale Sold out

1 Description

The Fiber Mall 40G QSFP+ SWDM4 transceiver modules are designed for use in 40G Ethernet links over duplex multimode fiber. Four channels/lanes in the 850-940nm region @ 10Gbps to transport the Ethernet signal. Digital diagnostics functions are available via an I2C interface, as specified by the QSFP+ MSA.

2 Product Features

  • Compliant with QSFP+ MSA
  • Compliant with SWDM MSA
  • Compliant with SFF-8636
  • Compliant with IEEE 802.3ba
  • Hot-pluggable QSFP+ form factor
  • 4x10Gb/s VCSEL-based SWDM transmitter
  • Supports 41.2Gbps aggregate bit rate
  • Power dissipation<3.5W
  • Maximum link length of 240m on OM3 MMF and 350m on OM4 MMF
  • Case temperature range of 0°C to 70°C
  • Duplex LC receptacles
  • XLPPI electrical interface
  • RoHS compliant

3 Application Scenario

  • XLPPI electrical interface

4 Order Information

Part Number

Product Description


850nm, 40Gbps, LC, 350m, 0°C~+70°C, with DDM
