QSFP DD 800G SR8 Transceiver 800G SR8 QSFP DD 850nm 100m OM4 MMF MPO-16
QSFP DD 800G SR8 Transceiver 800G SR8 QSFP DD 850nm 100m OM4 MMF MPO-16
Regular price
$2,194.29 USD
Regular price
Sale price
$2,194.29 USD
Unit price
/
per
Couldn't load pickup availability
1 Description
The QSFP DD 800G SR8 Transceiver is a pluggable transceiver for short-range data communication and interconnect applications. Each Transceiver has 8 duplex channels with 800Gb/s aggregate bandwidth. Each channel operates with PAM4 modulation scheme at 53.125GBd baud rate, and up to 100m using OM4 fiber.
2 Product Features
- QSFP-DD MSA and 800G Ethernet Compliant
- 800GAUI-8 electrical interface
- Bidirectional operation : 8xTx and 8x Rx at 106.25Gb/s with 53.125GBd PAM4 modulation scheme
- Built in DSP
- Enabled by 850nm VCSEL
- Operating case temperature 0°C~70°C
- Hot pluggable
- Power consumption 13W per end
- Transmission distance up to 100m with om4 fiber
- Laser eye safety Class 1
- CMIS 5.0 management interface
3 Application Scenario
- 800G Ethernet
- Data Center Interconnect
- Infiniband Interconnects
4 Order Information
Part Number |
Product Description |
QSFP DD 800G SR8 |
800G SR8 QSFP DD 850nm 100m OM4 MMF MPO-16 |
